16K Kraftsman Deckover Flatbed Tilt Trailer
Trailer Specifications
The following configurations of this trailer are available to best suit your needs.
Construction
- 10” @ 12 lb. I-Beam Main Frame
- 3” Crosspieces on 16” Centers
- Rub Rail with Stake Pockets & Chain Spools
- Diamond Plate Steel Approach Plate
Electrical
- Lifetime LED Lights, Rubber Mounted
- Marker Lights on Front of Trailer & Steps
- USA Made Sealed Wiring Harness
- 3 Way 12V DC Pump
Undercarriage
- 8,000 lb. EZ Lube Axles
- 4 x 235/85 R16 14 Ply Radial Tires
- 8 on 6.5” Bolt Pattern
- Slipper Spring Suspension
Dimensions
- 16,000 lb. GVWR, 12,000 lb. Max Capacity
- 102” Wide x 22’ Deck Standard, 24' & 26’ Available
- Approx. 35” Deck Height
- Approx. 6’ Cold-Formed Tongue
Additional Features
- Nominal 2'' Pressure Treated #1 Pine Deck
- Single 12K Drop-Leg, Spring-Loaded Jack
- 2-5/16” Adjustable Coupler
- Large Front Tool Box
Finish
- High Pressure Phosphate Wash
- Primed Top & Bottom w/ Automotive Primer
- Two Top Coats of 2-Part PPG Black Gloss
- DOT Reflective Tape, Kraftsman Decals
- Safety & Operational Decals
About The FT-16 Deckover Full Tilt Equipment Trailer
Kraftsman Trailer's model FT-16 is a 16K deckover full tilt equipment trailer is designed for hauling equipment like tractors, skid steers, and cargo like vehicles and storage containers. The 16,000 GVWR trailer is constructed with a 10” 12-pound I-beam frame and 3” crosspieces on 16” centers, and 2 x 8,000 Dexter EZ-Lube axles.
Standard features on the FT-16 full tilt trailer include 16" wheels with 14 ply radial tires, 2" pressure treated pine deck floor, 12.25" x 2.5" brakes on both axles, diamond plate steel approach plate, and a lockable front toolbox. This model comes with a 35" approximate deck height and a 22' standard tilt deck for easy loading and unloading, with other lengths available.
The FT-16 hydraulic full tilt equipment trailer has a 16,000 GVWR rating with a 12,000 lb. max capacity, and is available in three deck sizes: 102'' x 22', 102” x 24’ and 102” x 26’. A heavy duty package that puts crosspieces on 12" centers and and includes a tire upgrade is also available. Additional options are available!
Contact us today to make this 16,000 GVWR trailer yours! A gooseneck version is available. This trailer model is also offered in 14k and 21k GVWR's.
